A workspace holds the part, weld, probes, beamsets and indications. Open reads a local .ebwk file; Export writes one. Signed-in subscribers can also keep workspaces in their account and reload them from any device.
The workbench keeps an undo history for every set-up dialog. Cancel in a dialog restores the state from when it was opened; Apply to scene keeps your changes as one undo step.
